LED Power Supply

Feature:

1.AC input range selectable by switch

2.Withstand 300VAC surge input for 5 second

3.No load power consumption<0.5W

4.Miniature size and 1U low profile

5.High operating temperature up to 70℃

6.Protections: Short circuit/Overload/oOver Voltage/Over temperature

7.Cooling by free air convection

8.Compliance to IEC/EN 60335-1(PD3) and IEC/EN61558-1, 2-16 for household appliances

9.Operating altitude up to 5000 meters

10.Withstand 5G vibration test

11.High efficiency, long life and high reliability

12.LED indicator for power on

13.Over voltage category Ⅲ

14.100% full load burn-in test

15.3 years warranty

Description:

LRS series is a single output enclosed type power supply with 30mm of low profile design.

Adopting the input of 115VAC or 230VAC(selectable by switch), the entire series provides

an output voltage line of 12V, 15V, 24V, 36V and 48V.

 In addition to the high efficiency up to 90%, the design of metallic mesh case enhances

the heat dissipation of LRS series that the whole series operates from -30℃ through 70℃

under air convection without a fan. Delivering an extremely low no load power consumption

(less than 0.5W), it allows the end system to Rated wattage vibration capability; it is complied

with the international safety regulations such as TUV EN62368-1, EN60335-1,EN61558-1/-2-16,

UL62368-1 and GB4943. LRS-150 series serves as a high price-to- performance power supply

solution for various industrial applications.

Application:

Industrial automation machinery, Industrial control system, Mechanical and electrical equipment,

Electronic instruments, Equipments or Apparatus, Household applications.
