Power Supply
Home >> Products > Power Supply

LED Power Supply

Code:

HLG-240H

Input Voltage:

AC90-305VAC

Output Voltage:

DC12-54V

Power:

240W

Output Power:

Max 10.0A

Size:

220×68×38.8MM

Inquire  Add to Basket
PRODUCT DETAILS

Feature:

1.Constant Voltage + Constant Current Mode Output

2.Metal housing with class I design

3.IP67 / IP65 rating for indoor or outdoor installations

4.Function options: output adjustable via potentiometer; 3 in 1 dimming

5.Typical lifetime > 62000 hours

6.7 years warranty

Description

HLG series is a AC/DC LED driver featuring the dual mode constant voltage and constant current output.

HLG operates from 90-305VAC and offers models with different rated voltage ranging between 12V and 54V

current output. HLG-240H operates from 90~305VAC and offers models with different rated voltage ranging.

Thanks to the high efficiency up to 93.5%, with the fanless design, the entire series is able to operate for

-40℃ ~ +90℃ case temperature under free air convection. The design of metal housing and IP67/IP65 ingress

protection level allows this series to fit both indoor and outdoor applications. HLG-240H is equipped with various

function options, such as dimming methodologies, so as to provide the optimal design flexibility for LED lighting

system

Application:

LED street lighting, LED high-bay lighting, Parking space lighting, LED fishing lamp, LED greenhouse lighting,etc
QUALITY MANAGEMENT
CARGO LOADING
